INTRODUCTION
Component Identification
A — Regeneration Valve
B — Hook Cylinder
C — Hook D — Guide Track-Slide Rod
E — Guide Track
F — Sensor, Magnetic Reed Switch
(Replaces Proximity Switch) G — Positioning Cylinder
H — Guide Track Harness - Includes 4 Magnetic
Reed Switches, Assembled
I — Hook Lowered Sensor Target
J--Pressure Differential
Valve
New Telemecanique “TWIDO” Programmable Logic Controller
4111-0010 — Nov 2010 9
J
G
B
A
F
C
D E
H
I
