68 Asanté FriendlyNET Internet Router with Firewall
Status Indicators
Ports
06-006 75-00, Rev. A
As
ant
é Fr
iend
lyN
ET
In
ter
net
R
ou
ter
, F
R
10
00 S
eries
· U
ser
’s G
uid
e
Label Description
Power FR1004: On when the router has power
Status Blinks during power on self-test
Link/Activity On with valid network connection; blinks when there is network activity
100 Mbps On for 1000 Mbps (Fast Ethernet); off for 10 Mbps
Printer FR1004AL: On when print server is active
Wireless FR1004AL: Blinks rapidly when there is wireless network activity
Ports Connection Specification
1, 2, 3, 4 To 10/100 Fast Ethernet ports for your
computers (LAN) RJ-45, 10/100 Fast Ethernet with
Auto-Uplink
Internet To your cable/DSL modem RJ-45, 10/100 Fast Ethernet with
Auto-Uplink
Printer FR1004AL: To your printer 25-pin D-type parallel, standard paral-
lel (unidirectional)
5 VDC To the power module (included) 5 VDC, center is positive polarity
To reset the router to factory defaults. Locate the reset button on the router.
Turn off the power to the router. Using a pen, hold in the reset button and turn
on the power to the router. In a few minutes, the router’s status indicators will
stop flashing and the default factory settings will be loaded.
