Installation
F232102 34
Steam Requirements
(Steam Heat Option Only)
For washer-extractors equipped with optional steam
heat, install piping in accordance with approved
commercial steam practices. Steam requirements are
shown in Table 7.
NOTE: Failure to install the supplied steam filter
may void the warranty.
Air Requirements
Air supply requirements are shown Table 8, Table 9
and Table 10.
Cabinet Freestanding
Steam Supply Information
135 250
Steam inlet connection 3/4 in.
(DN20)
(19.05 mm)
1 in. (DN25)
(25.4 mm)
Number of steam inlets 1 1
Recommended pressure 30 – 80 psi
(2.0 – 5.5 bar)
30 – 80 psi
(2.0 – 5.5 bar)
Maximum pressure 80 psi
(5.4 bar)
80 psi
(5.4 bar)
Table 7
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING
Standard 135 Pound Cabinet Freestanding
Air Supply Information
Inlet size 1/4 in. (DN8)
(6.35 mm)
Recommended pressure 25 – 100 psi
(1.7 – 8 bar)
Average consumption 0.1 CFM
(.003 CMM)
Table 8
Standard 250 Pound Cabinet Freestanding
Air Supply Information
Inlet size 1/4 in. (DN8)
(6.35 mm)
Recommended pressure 25 – 100 psi
(1.7 – 8 bar)
Average consumption 0.1 CFM
(.003 CMM)
Table 9
250 Pound Cabinet Freestanding with Tilt Air
Supply Information
Inlet size 1/4 in. (DN8)
(6.35 mm)
Recommended pressure 80 – 100 psi
(5.5 – 6.9 bar)
Average consumption 1.5 CF/tilt
(.05 CM/tilt)
Table 10
