Installation
29
F232102
Cabinet Freestanding
Drain Information
135
250
Drain connection size, I.D.
4 in.
(102 mm)
4 in.
(102 mm)
Number of drain outlets
1
1
Drain flow capacity
150 gal/min
(568 l/min)
150
gal/min
(568 l/min)
Recommended drain pit size
15.4 ft
3
(433 l)
30.0
ft
3
(844 l)
Table 3
Cabinet Freestanding
Drain Line Sizing
Minimum Drain I.D.
Model
Number of Machines
1
2
3
4
135
4 in.
(102 mm)
4
in.
(102 mm)
6
in.
(152 mm)
6
in.
(152 mm)
250
4 in.
(102 mm)
6
in.
(152 mm)
6
in.
(152 mm)
6
in.
(152 mm)
Table 4
