Installation
13 F232102
135 250
Standard Standard
Forward Tilt
Option
Two-Way
Tilt Option
Water Consumption
Average water consumption per cycle HOT
COLD
153 gal
(579 l)
219 gal
(829 l)
219 gal
(829 l)
219 gal
(829 l)
70 gal
(266 l)
105 gal
(399 l)
105 gal
(399 l)
105 gal
(399 l)
Average hot water consumed per hour 220 gal
(833 l)
285 gal
(1079 l)
285 gal
(1079 l)
285 gal
(1079 l)
Power Consumption
Average power used per cycle
0.9 kW-hr
1.5 kW-hr
(Est.)
1.5 kW-hr
(Est.)
1.5 kW-hr
(Est.)
Average HVAC load 1500 BTU/hr
(kcal/hr)
2200 BTU/hr
(kcal/hr)
2200 BTU/hr
(kcal/hr)
2200 BTU/hr
(kcal/hr)
Nominal sound emission 75 dBA 75 dBA 75 dBA 75 dBA
Drive Train Information
Number of motors in drive train 1 1 1 1
Drive motor power
10 hp
(7.5 kW)
25 hp
(18.5 kW)
25 hp
(18.5 kW)
25 hp
(18.5 kW)
Cylinder Speeds
1/2 Wash/reverse speed 26 rpm 21 rpm 21 rpm 21 rpm
Wash/reverse speed 36 rpm 31 rpm 31 rpm 31 rpm
Distribution speed 62 rpm 54 rpm 54 rpm 54 rpm
Medium extract speed 170 rpm 140 rpm 140 rpm 140 rpm
High extract speed l 375 rpm 340 rpm 340 rpm 340 rpm
High extract speed 2 480 rpm 435 rpm 435 rpm 435 rpm
High extract speed 3 715 rpm 650 rpm 650 rpm 650 rpm
Centrifugal Force Data
1/2 Wash/reverse centrifugal force 0.412 Gs 0.325 Gs 0.325 Gs 0.325 Gs
Wash/reverse centrifugal force 0.790 Gs 0.708 Gs 0.708 Gs 0.708 Gs
Distribution centrifugal force 2.34 Gs 2.15 Gs 2.15 Gs 2.15 Gs
Medium extract centrifugal force 17.6 Gs 14.7 Gs 14.7 Gs 14.7 Gs
High extract 1 centrifugal force 85.8 Gs 85.3 Gs 85.3 Gs 85.3 Gs
High extract 2 centrifugal force 141 Gs 140 Gs 140 Gs 140 Gs
High extract 3 centrifugal force 312 Gs 312 Gs 312 Gs 312 Gs
Balance Detection
Vibration safety switch installed Standard Standard Standard Standard
Cabinet Freestanding
135 Pound and 250 Pound Capacity Models
General Specifications (Continued)
