Installation
F232102 20
Figure 7
CFS219N
36 in. (914 mm) RECOMMENDED
30 in. (762 mm) ALLOWABLE
18 in.(475 mm)
COMPACTED FILL DIRT
13 in.
(330 mm)
13 in.
(330 mm)
103.25 in.
(2622 mm)
6
in.
(152
m
m
)
MI
N
IM
U
M
F
L
O
O
R
T
H
ICKNE
S
S
13° 13°
250 POUND CAPACITY MODELS WITH FORWARD AND TWO-WAY TILT OPTION
