© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT M414545 47
Figure 20
WARNING! DO NOT
OPERATE WITHOUT
GUARDS IN PLACE.
TMB1966N
NOTE: Tumbler is shown with guards removed for ilustration purposes only.
Never operate the tumbler with the guards removed.
CYLINDER
DRIVE CHAIN
CYLINDER
SPROCKET
SHEAVE
IDLER
SPROCKET
JAMNUT
DRIVE
SPROCKET
IDLER
HOUSING
GUIDE
RAIL
GUIDE RAIL
WASHER
GROUND WIRE
(Green)
MOTOR
PULLEY
V-BELT
ONE HALF
INCH
(1.27 cm)
DEFLECTION
BELT ADJUSTING
BOLT AND NUT
ONE HALF INCH
(1.27 cm)
DEFLECTION
NONREVERSING
CHAIN DRIVE MODELS
