6.0 Appendices
Appendix A – Specifications
SAMPLE GAS INLET TEMPERATURE 65°C (150°F) MAX.
30 PSIG MAX.
SAMPLE GAS PRESSURE/VACUUM
-1 in. Hg MIN.
SAMPLE FLOW RATE 0.5 to 1.0 LPM
115VAC, 1.2A ELECTRICAL REQUIREMENTS
(Not including heated line power of 10A max.)
220VAC, 0.6A
GAS INLET/OUTLET FITTINGS ¼” TUBE COMPRESSION FITTINGS
OPERATING ENVIRONMENT 10°C to 40°C AMBIENT, 0 to 95% R.H.
NAFION TUBE INNER DIAMETER 0.060" +/- 10%
SAMPLE GAS INLET HUMIDITY (DEW POINT, ºC) 55°C (130°F) MAX.
SAMPLE GAS INLET HUMIDITY (% BY VOL.) 15% MAX.
GAS % LOSS
NO 0
NO2 0
SO2 0
CO 0
CO2 0
H2S 0
SOLUABLE GAS REMOVAL RATES
HCl 0
