Electrical Requirements
70304601
40
Electrical Requirements for Gas and
Steam Models
Refer to Table 10 and Table 11.
NOTE: Minimum wire sizes are obtained from
Canadian Electrical Code for 75°C Conductors and
are intended for use as a guideline only. Electrical
connections should be made only by a qualified
electrical contractor in accordance with all
applicable local and national requirements.
For T30 Gas and Steam Models
(For Total Machine):
NOTE: Electrical specifications below are subject
to change without notice. Always refer to product
serial plate for most current specifications of
product being installed.
NOTE: Use copper conductors only.
NOTE: 3 Phase Only – Each tumbler must be
connected to its own individual branch circuit
breaker, not fuses, to avoid the possibility of “single
phasing” and causing premature failure of the
motor(s).
Table 10
Serial Plate
Voltage
Terminal Block
Connections
Required
Current
(Amps)
Recommended
Fuse or
Breaker Rating
(Amps)
Breaker
Poles
Recommended
Minimum
Conductor Size
[AWG (mm
2
)]
120V/60 Hz/1ph
L1, Neutral,
and ground
16.0
20
1
12 (3.31)
208-240V/60Hz/
1ph
L1, L2, Neutral,
and ground
8.0
10
2
14 (2.08)
100V/60Hz/1ph
L1, Neutral,
and ground
22.0
30
1
10 (5.26)
200-220V/60Hz/
1ph
L1, Neutral,
and ground
11.6
15
1
14 (2.08)
100V/50Hz/1ph
L1, Neutral,
and ground
24.2
35
1
8 (8.37)
200V/50Hz/1ph
L1, Neutral,
and ground
15.0
20
1
12 (3.31)
230-240V/50Hz/
1ph
L1, Neutral,
and ground
15.0
20
1
12 (3.31)
200-208V/60Hz/
3ph
L1, L2, L3,
and ground
6.4
10*
3
14 (2.08)
240V/60Hz/3ph
L1, L2, L3,
and ground
6.4
10*
3
14 (2.08)
200V/50Hz/3ph
L1, L2, L3,
and ground
5.8
10*
3
14 (2.08)
230-240V/50Hz/
3ph
L1, L2, L3,
and ground
7.0
10*
3
14 (2.08)
380V/50 or 60Hz/
3ph
L1, L2, L3,
and ground
3.0
10*
3
14 (2.08)
400-415V/50Hz/
3ph
L1, L2, L3,
and ground
3.2
10*
3
14 (2.08)
460-480V/60Hz/
3ph
L1, L2, L3,
and ground
3.3
10*
3
14 (2.08)
*
3 Phase machines should not have fuses, breakers only.
