A proper installation of the AeGIS system is very essential. You MUST follow the installation-wiring steps as shown in figure
2.1, 2.2, 2.3 and 2.4

Figure 2.1 Intercom with Dedicated Phone line Wiring Diagram

Pach and Company

Page 4

AeGIS 400RTP

Chapter 2. Installation
