Page 7

7
Included on the data plate is the model number of the pump. Each
number in the model number represents the following in Figure 3b.
HH XXX-987
Figure 3a : Data Plate
Liquid End
Output Codes
Series
or Model
Cord & Voltage Codes
1 = 120 V US plug, UL
2 = 240 V US plug, UL
3 = 230 V DIN plug, CE
5 = 240 V UK plug, CE
6 = 250 V Aust/ NZ plug
7 = 230 V Swiss plug
8 = 120 V No plug, CE
Figure 3b : Model Number Representation
1 = 0.14 GPH at 300 PSI
2 = 0.10 GPH at 600 PSI
3 = 0.07 GPH at 1000 PSI
4.0 How to Interpret the Model Number
The silver data plate (located on the front of the pump) tells you how
your pump is configured.
115 V.A.C.
1.4 A
MODEL # HH931-987
SERIAL #
MAX/
GPH
0.07
PSI
1000
Control Code
1 = Manual
7 = Instrument
Responsive Manual
9 = Microprocessor/
Instrument
Responsive
50/60 HZ.
