Page 70

6-4
Processing media
DOC D00 025-A
6.2.1
Inserting cartridges
New cartridges are inserted in the AML/J through the I/O unit.
Step 1
Press the button on the I/O unit
The button on the I/O unit lights up green and the I/O unit is
unlocked
Step 2
Open the door of the I/O unit
Step 3
Empty the problem box places if cartridges are there
Step 4
Insert the cartridges in the I/O unit. Pay attention to the correct
position.
• Tape head down
• Label to the front
Step 5
Close the door of the I/O unit
The AML/J locks the I/O unit .
According to configuration, the robot checks the magazine (barcode or
empty place) on the cartridges.
Step 6
Move the cartridge with the aid of the host software into the
archive
(exception: foreign mount cartridges)
The cartridges are brought into the archive.
