Dl1142 diagram, Nitek, Dl1142 – Nitek DL1142 User Manual
Page 7: Rs422 line driver
7
DL1142 Diagram
2.6"
1.1"
4.3"
NITEK
800-528-4343
WWW
.NITEK.NET
R
OLLING MEADO
WS
, IL 60008
DL1142
RS422 Line Driver
Extends RS422 to 12,000 f
eet
MADE IN USA
54-114-0101
RS422 IN TERMINA
TION JUMPER LOCA TED
INSIDE COVER ON BO
TTOM OF UNIT
RS422
-
OUTPUT
RS422
+
OUTPUT
RS422
-
IN
RS422
+
IN
PO
WER
14
-
18
VDC
140mA
-
+
RS422
-
IN
RS422 + IN
DL1142
DRIVER
RS422
-
OUT
RS422 + OUT
twisted pair
up to 12,000 ft
EAR
TH GR
OUND
WIRE
EAR
TH
GR
OUND
