Page 9
PoE Distance Chart
* Results charted were calculated using four pair 24awg Cat5e cabling
27.4
27.4
25.0
20.0
18.0
30.0
25.0
20.0
15.0
10.0
5.0
500 Meters
1,640 Feet
400 Meters
1,300 Feet
300 Meters
1,000 Feet
200 Meters
650 Feet
100 Meters
328 Feet
27.4 Watts
27.4 Watts
25.0 Watts
20.0 Watts
18.0 Watts
W
att
s
14.1
600 Meters
1,960 Feet
14.1 Watts
568B Pinout Termination
