Installation Manual

FTS312104S00 Mini Transmitter

1 Camera Transmitter w/Data and Aux Comm.

Note: This installation should be made by a qualified
service person and conform with local codes.

Reduce risk of fire or electrical shock do

not expose this product to rain or moisture.

!

Specifications

Video Connection
Connector

75 ohm BNC Socket

Input Impedance

75 ohm terminated

Input Level

1 volt p-p nominal

Frequency Response

10Hz to 5.75MHz

Optical Connection
Connector

SC

Style

Path Loss

20 dB

No Customer adjustments are available within the unit.
Wavelength

1310

/

1550nm

Power Connection
Supply

12 to 24VDC @ 150mA

Auxiliary Ports
Data Selectable

RS422/RS485/RS232

Alarm

In

Contact

Closure

Alarm Out Relay

100V 150mA max

NITEK

®

5410 Newport Drive, Suite 24
Rolling Meadows, IL 60008
PHONE (847) 259-8900
FAX (847) 259-1300
WWW.NITEK.NET

Installation Instructions

- The mini fiber transmitter is designed to be mounted using the included bracket.
- Always allow for bend radius of optical and electrical cables when installed.
- There are no adjustments required when using this product.

680600115 Rev 02052009

Service Information

There are no user serviceable parts inside the unit. In the event that service is required to this unit please
contact NITEK Technical Support at 800-528-4343.

NITEK

R

OPTO OUT

VIDEO IN

12-24 AC\DC

150mA 50\60 Hz

Class 2 only

POWER

VIDEO / OPTO

DATA OUT

DATA IN

ALARM OUT

ALARM IN

RS485

RS422

RS232

RS232

RS485 RS422

DATA

IN + (A)

IN - (B)

OUT + (A)
OUT - (B)

GND

7
8
7
8
6

1
2
7
8
6

2
-
8
-
6

PIN

ALARM

OUT +

OUT -

IN +

GND

3

4

5

6

1

2

3

4

5

6

7

8

NITEK

R

OPTO OUT

VIDEO IN

12-24 AC\DC

150mA 50\60 Hz

Class 2 only

POWER

VIDEO / OPTO

DATA OUT

DATA IN

ALARM OUT

ALARM IN

RS485

RS422

RS232

RS232

RS485 RS422

DATA

IN + (A)

IN - (B)

OUT + (A)
OUT - (B)

GND

7
8
7
8
6

1
2
7
8
6

2
-
8
-
6

PIN

ALARM

OUT +

OUT -

IN +

GND

3

4

5

6

1

2

3

4

5

6

7

8

FIBER IN/OUT

VIDEO IN

CONTACT IN

CONTACT OUT

POWER
SUPPLY

Color Description

Green System

Normal

Yellow (RX) Link working, No video at TX

Red

(TX) Power on, No video into TX
(RX) Power on, No opto into RX

Power/Video/Opto LED

Color Description

Green

Data is Low / Logic 0

Red

Data is High / Logic 1 (RS422/485)

Off

Data is Tri-state / (High - RS232)

Data LED
