40’ navi-trac component list – Anchor Industries NAVI-TRAC NAV40GBL-1104 User Manual
Page 6
6
I.D.
40’ GABLED END NAVI-TRAC
LABEL
(LETTER ON
DRAWING)
COMPONENT DESCRIPTION
CODES
(STAMPED OR
TAPED)
GBL
KIT
1
GBL
KIT
2
HIP
KIT
3
20’
MID
STR
20’
MID
EXT
15’
MID
STR
15’
MID
EXT
10’
MID
STR
10’
MID
EXT
STAKES, CABLES & WEB GUYS
**OPTIONS OF 10’,15’, OR 20’ BAYS MUST
BE SPECIFIED.
G
NAVI-TRAC WEB GUYS
2
5
2
2
2
2
2
2
T-30
1” x 30” STEEL STAKES
2
3
2
2
2
2
2
2
T-42
1 1/8” x 42” STEEL STAKES
2
5
2
2
2
2
2
2
X-1
UPRIGHT X-CABLES FOR 10’ MID BAY**
GREEN
NAV-BAY10-U8
[4] [4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X-2
UPRIGHT X-CABLES FOR 15’ MID BAY**
GREEN
NAV-BAY15-U8
[4] [4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X-3
UPRIGHT X-CABLES FOR 20’ MID BAY**
GREEN
NAV-BAY20-U8
[4] [4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X4
LOWER ROOF X-CABLES FOR 10’ MID BAY
A**
RED
NAV-BAY10
4
4
X5
LOWER ROOF X-CABLES FOR 15’ MID BAY
A**
RED
NAV-BAY15
4
4
X6
LOWER ROOF X-CABLES FOR 20’ MID BAY
A**
RED
NAV-BAY20
4
4
X7
UPPER ROOF X-CABLES FOR 10’ MID
BAYB**
BLUE
NAV40-BAY10
4
4
X8
UPPER ROOF X-CABLES FOR 15’ MID BAY
B**
BLUE
NAV40-BAY15
4
4
X9
UPPER ROOF X-CABLES FOR 20’ MID BAY
B**
BLUE
NAV40-BAY20
4
4
BOLTS AND HARDWARE
LANYARD ASS’Y W/HAIRPIN COTTER
4
1/2”-13 x 3” BOLT W/NYLOCK NUT
6
4
10
2
2
2
2
2
2
1/2”-13 x 3 1/2” BOLT W/NYLOCK NUT
6
6
INSTALLATION TOOLS
CROSS CABLE FOR 40’
BLUE
1
1
1
1
1
1
LOWER SAFETY STRAP W/RATCHET
4
UPPER SAFETY STRAP FOR 10’ BAYS
4
UPPER SAFETY STRAP FOR 15’ BAYS
4
UPPER SAFETY STRAP FOR 20’ BAYS
4
1/2” GRAVITY PIN (FOR CROSS CABLE)
2
2
2
2
2
2
LONG LIFTING CRADLE
1
PUSH POLE EXT. (FOR LONG CRADLE)
1
SHORT LIFTING CRADLE
1
ADJ. BASEPLATE GUIDE BAR
2
FABRIC PULL ROPES
2
WHEELED PANEL GUIDES
2
DROP CLOTH (8’ x 30’)
1
40’ NAVI-TRAC COMPONENT LIST
CONTINUED FROM PREVIOUS PAGE
