HIP/GABLED END COMBINATION UNIT
SEE THE STANDARD NAVI-TRAC
INSTALLATION INSTRUCTIONS FOR
ASSEMBLY OF THE HIP END UNIT.
EXTENSION BEAMS ARE PIVOTED
IN THE SAME MANNER AS SHOWN
ABOVE IN THIS GABLED END
ASSEMBLY INSTRUCTION.
SEE BELOW FOR COMPONENTS
THAT MUST BE SUBSTITUTED IN
HIP END UNIT (SEE KIT #3)
E20
EIW
CW
BFW
H21-4
MRW
EFW
TFW
MLW
HIP (KIT #3) COMPONENTS
(NOTE: MRW & MLW ARE SUPPLIED
WITH THE “STARTER’ FRAMES)
E20
H7-6
R21-9
B1
BFW
B4
