2.4.1 Relay Strike Time
Default setting for Relays 1 and 2 is 01 (1 Second). Relays 3 through 8 are not set.
These steps will program the system relay strike times. Strike times can be programmed from 1/4
second (enter 00 in step 3) up to 99 seconds.
System relays 1 and 2 are the two relays on the 1838 main circuit board. System relays 3 through 8
are the relays associated with additional RS-485 devices (card readers, keypads, RF receivers, etc.)
connected to the system.
1. Press * 0 3 and enter the MASTER CODE. [ * 0 3 _ _ _ _ (beep)]
2. Enter a relay number (1 – 8), then press *. [ _ * (beep)]
3. Enter the two-digit strike time (00-99) then press *. [ _ _ * (beep)]
4. Repeat steps 2 and 3 to set other relay strike times.
5. Press 0# TOGETHER to end. [0# (beeeeeep)]
2.4.2 Tone Open Numbers
Default setting is 9876 for relay 1; 5432 for relay 2. Relays 3 – 8 are not set.
NOTE: This programming sequence is applicable only if the 1838 will have a telephone line
connected to it.
These steps will program the tone open number(s) for each relay in the system (each relay is
programmed independently). You will need to enter a four-digit number (see chart below) to set each
relay. If a function is not desired, enter # in place of a number. For example, if you want the relay to
have a momentary activation function only, and you want the relay to activate when the number 9 is
pressed, enter 9 # # # in step 3.
1. Press * 0 5 and enter the MASTER CODE. [ * 0 5 _ _ _ _ (beep)]
2. Enter a relay number (1 – 8), then press *. [ _ * (beep)]
3. Enter the four-digit tone open number code then press *. [ _ _ _ _ * (beep)]
4. Repeat steps 2 and 3 to set other relay tone open numbers.
5. Press 0# TOGETHER to end. [0# (beeeeeep)]
4 Digit Tone
Open
Number
Code
Function
1
st
Digit Momentary activation. The relay will activate for its programmed strike time.
2 nd Digit Hold open. The relay will activate and remain activated until commanded to deactivate.
3 rd Digit Deactivate relay.
4
th
Digit Hold open 1 hour. The relay will activate for 1 hour and then deactivate itself.
1838-066-D-1-12 Page 25
