1.9 Modem Connections
The 1838 Access Plus has a built-in modem that can be used to connect to a PC. Before
programming can be attempted, you need to install the programming software on the computer you
want to use for this purpose. The computer must have modem installed or an external modem
connected to it. Follow the instructions in the programming software help guide for setup information.
Modem Connection
