1812-162-M-1-12 24
• Through the internet with a static IP address. This is a Wide Area Network (WAN) connection and will require a router
and a DSL or cable modem with an internet connection.
• Through the internet with a dynamic IP address. This is a Wide Area Network (WAN) connection and will require a
router and a DSL or cable modem with an internet connection. You will also need a registered DDNS host name.
SOFTW
ARE
INST
ALLED
Through the Internet (WAN)
MOD EM / TCP E
NB
1972-
010
SW 1
1
2
3
4
5
6
7
8
BAD
DN S LA N DO WN
RS- 485 RX
J4
ON
J1
RJ-
45 Jack
(Cat5)
SOFTW
ARE
INST
ALLED
DSL Modem or
Cable Mod
em
PC with Internet Access
Laptop with Internet Access
(Wireless is opti
onal)
Internet
Phone Company or
Cable Company Input
RJ-45
RJ-45
RJ-45
RJ-45
Cable
(Cat5)
Internet 1
2
3
4
Cat
5
Cat
5 f
or LAN Connecti
on
Cat
5 f
or W
AN Connection
Wired or Wire
less
Router
(Wirele
ss shown)
Maximum distance on
Cat5 wire run is limited
to 325 feet (100 meters).
Router address: 192.168.001.001
Note: 1812 address is set to
192.168.001.030
(See 2.3.2 Set the 1812 IP
address). The 1812 address
must be “unique” within the
LAN network. This allows a
computer to locate the 1812
within the LAN.
Note: The gateway address must set into the
1812. This allows the 1812 to “register” with the
LAN 192.168.001.001
(See 2.3.4 Set the gateway (router) IP address).
Note: Connect to the 1st 1812
Access Plus when multiple units
are connected together.
A computer searches
for 192.168.001.030
in the network.
SW2 ON
