Section 5
50 Ton Ram Instruction Manual
Release both cam arms.
Put the spacer rings between the ferrule and coupler
head, making sure that the two ring halves meet
over the turned over portion of the ferrule.
Remove the gasket from the coupler.
For “C” style couplings requiring spacer rings:
12c
12d
12a
12b
Insert the proper pusher into the coupler (reference
the chart at the end of this section for proper pusher
selection).
