Dixon Valve 100 TON RAM SEC10 Parts and Attachments User Manual
Page 5
Parts & Attachments
3
Section 10
100 Ton Ram Instruction Manual
100 Ton Ram
Equipment to Swage 1" through 4" Cam & Groove
M011-065
4" Pusher (
Needed For All Sizes
)
100PUSHCG4E
Pusher for 4" E
100PUSHCG4C
Pusher for 4" C
100PUSHCG3
Pusher for 3" E (
fits on 100PUSHCG2
)
100PUSHCG2
Pusher for 2" C and E and 3" C
100PUSHCG15
Pusher for 1 ½” C (
two parts
)
100PUSHCG15E
Pusher for 1 ½” E
100PUSHCGRC
Pusher for 1" C and E
400CGSPACE *
Spacer Rings for 4" C
300CGSPACE *
Spacer Rings for 3" C
200CGSPACE *
Spacer Rings for 2" C
150CGSPACE *
Spacer Rings for 1 ½” C
100CGSPACE *
Spacer Rings for 1" C
Swage Dies Not Included
* Future designs may not require Spacer Rings.
Contact the Factory for more information.
