50 Ton Ram Instruction Manual
Parts & Attachments
customer service 800 • 355 • 1991
2 Section 10
50 Ton Ram
Equipment to Swage 1" through 4" Cam & Groove
MPUSH600 6" Pusher (needed for all sizes)
50TPUSH400 4" Pusher
50TDH9004 Die Holder for 4" die (needed for all sizes)
50TDH6003 Die Holder for 1¼" - 3" dies (fits into 50TDH9004)
100PUSHCG4E Pusher for 4" E
100PUSHCG4C Pusher for 4" C
100PUSHCG3 Pusher for 3" E (fits on 100PUSHCG2)
100PUSHCG2 Pusher for 2" C and E and 3" C (also use with 100PUSHCGRC and RE100PUSH)
100PUSHCG15 Pusher for 1½" C and E (consists of 100PUSHCG15A and RC150PUSHB)
100PUSHCG15A 1½" Pusher Adapter
RC150PUSHB 1½" Pusher
100PUSHCGRC Pusher for 1" C & G (fits inside the 100PUSHCG2)
RE100PUSH Pusher for 1" E (use with 100PUSHCG2)
150CGSPACE * Spacer Rings for 1½" C
100CGSPACE * Spacer Rings for 1" C
RST150SPACE 1½" Spacer Ring for NOS ferrules (use with 100PUSHCG15E)
RST200SPACE 2" Spacer Ring for NOS ferrules (use with 100PUSHCG2)
RST300SPACE 3" Spacer Ring for NOS ferrules (use with 100PUSHCG3)
Swage Dies Not Included
* Future designs may not require Spacer Rings.
Contact the Factory for more information.
