25 Ton Ram
Equipment to Internally Expand Holedall Petroleum Fittings (cont.)
25000HTL03 1" IX Plug
25000HTL02 3/4" IX Plug
25000HTL01 5/8" IX Plug
25000HTL23 Thrust Plate for 4" H-520 Style Fittings
25000HTL22 Thrust Plate for 3" H-520 Style Fittings
25000HTL21 Thrust Plate for 2 ½” H-520 Style Fittings
25000HTL20 Thrust Plate for 2" H-520 Style Fittings
25000HTL19 Thrust Plate for 1-3/8" & 1 ½” H-520 Style Ftgs.
25000HTL18 Thrust Plate for 1 ¼” H-520 Style Fittings
25000HTL17 Thrust Plate for 1" H-520 Style Fittings
25000HTL16 Thrust Plate for 1" x 1 ½” H570 Style Fittings
Thrust Plate for 1" x 1 9/16" H-570 Style Ftgs.
25000HTL15 Thrust Plate for 1" x 1-25/64" H-570 Style Ftgs.
Thrust Plate for 1" x 1-29/64" H-570 Style Ftgs.
25000HTL14 Thrust Plate for ¾” H-520 Style Fittings
25000HTL13 Thrust Plate for ¾” x 1-7/32" H-570/H580 Ftgs.
25000HTL12 Thrust Plate for ¾” x 1-9/64" H-570/H580 Ftgs.
Thrust Plate for ¾” x 1-11/64" H-570/H580 Ftgs.
Thrust Plate for ¾” x 1-13/64" H-570/H580 Ftgs.
25000HTL11 Thrust Plate for 5/8" H-570 Fittings
* Consult the Factory for the necessary attachments to use the Scovill Style plugs (1 ¼”-4")
