Maintenance DZ-S2
Page 32 DZ-S2_e_0210.fm
0DLQWHQDQFH
0DLQWHQDQFH WDEOH
Service the system within the indicated
intervals in order to ensure:
- Safety for the operator
- Optimum performance
- Optimum reliability at all times
8QFRXSOH
wall sawing system
prior to performing maintenance
work on the unit
0DLQWHQDQFH LQWHUYDO $FWLRQ 5HPDUNV
weekly Check prism guides for wear Replace, EHIRUH anchoring screws of
prisms touch the rail or the wall saw
chassis touches the rail
weekly Check couplings for
- leaks
- damage Replace leaky or damaged couplings
weekly Grease Y-slide guides grease nipple 2-3 grease injections
weekly Check water couplings for
- leaks
- damage Replace leaky or damaged couplings
annually Change bearing housing grease Fill with 600 g gear grease (Page 34)
annually Major service Must only be performed by
HYDROSTRESS or a HYDROSTRESS
authorised representative
Correct maintenance procedures are described on the following pages.
