DZ-S2 Design and function
DZ-S2_e_0210.fm Page 15
)XQFWLRQ WDEOH
3RV QR 'HVLJQDWLRQ )XQFWLRQ
1 6DZ PRWRU
Saw blade drive
2
6DZ PRWRU FRXSOLQJ
Main circuit oil inlet
3
6DZ PRWRU QLSSOH
Main circuit oil outlet
4 )HHG PRWRU WUDYHO Drive (travelling motion)
5
)HHG PRWRU FRXSOLQJ
Feed circuit oil inlet or outlet (feed direction)
6
)HHG PRWRU QLSSOH
Feed circuit oil inlet or outlet (feed direction)
7
)HHG PRWRU VZLYHO
Drive (swivelling motion)
8 )HHG PRWRU FRXSOLQJ
Feed circuit oil inlet or outlet (swivel direction)
9
)HHG PRWRU QLSSOH
Feed circuit oil inlet or outlet (swivel direction)
10
&ODPSLQJ EORFN ZLWK GRZHO VFUHZ
V-rail anchoring
11 $GMXVWPHQW VFUHZV Compensation for uneven floor
12 )HHG JULS
Adjustment of play between wall saw head and rail
13
%ODGH JXDUG VHDW
Seat for blade guard
14 &ODPSLQJ KDQGOH Lock / release blade guard
15 &ODPSLQJ KDQGOH Lock / release side wing
16
:DWHU FRQQHFWLRQ
Water supply (cooling water)
Emergency stop
The wall sawing system can only be shut down on the drive unit. Follow the operating
instructions of the unit you are using.
