ITEM PART NO. QTY. DESCRIPTION
1 2600573 1 Baldor 1.5HP 115/230V Induction Motor
2 2900313 3 Cap Screw, Hex Hd., M8-1.25 x 30mm
3 2901583 12 M8 Washer (18mm OD)
4 2701762 1 Switch Box
5 2800309 1 Switch Box Lid W/Gaskets & Screws
6 2800232 1 Switch
7 2900009 2 Flat Washer, 1/4" SAE
8 2900024 2 Lock Washer, 1/4" Split
9 2900008 2 Cap Screw, Hex Hd., 1/4-20 x 1"
10 2900303 5 Lock Nut, M8-1.25 Nylon Insert
11 2902021 1 D18 x d8 - M8 x 1.25 x 87L Swing bolt
12 6030398 1 Motor Offset Mounting Plate
13 2800087 1 Plug, Nema L5-20P,125VAC-20Amp
14 2900336 1 Cap Screw, Hex Hd., M8-1.25 x 45mm
15 2800159 1 Toggle Switch, DPDT, On/On
16 2704740 1 Guard for Voltage Switch
17 2800355 1 Thermal Overload Switch - 1.5 HP Baldor
18 2800354 1 Rubber Reset Cover
1.5 HP - 1 Phase Electric Motor Mount Assembly
9
