ITEM

PART NO.

QTY.

DESCRIPTION

1

2600575

1

Baldor 3HP 1PH 220V-50 CCW Rotation

2

2900313

3

Cap Screw, Hex Hd., M8-1.25 x 30mm

3

2901583

12

M8 Washer (18mm OD)

4

2701762

1

Switch Box

5

2800309

1

Switch Box Lid W/Gaskets & Screws

6

2800232

1

Switch

7

2900009

2

Flat Washer, 1/4" SAE

8

2900024

2

Lock Washer, 1/4" Split

9

2900008

2

Cap Screw, Hex Hd., 1/4-20 x 1"

10

2900303

5

Lock Nut, M8-1.25 Nylon Insert

11

2902021

1

D18 x d8 - M8 x 1.25 x 87L Swing bolt

12

6030398

1

Motor Offset Mounting Plate

13

2800087

1

Plug, Nema L5-20P,125VAC-20Amp

14

2900336

1

Cap Screw, Hex Hd., M8-1.25 x 45mm

15

2800159

1

Toggle Switch, DPDT, On/On

16

2704740

1

Guard for Voltage Switch

17

2801028

1

Thermal Overload Switch - 3HP Baldor

18

2800354

1

Rubber Reset Cover

3.0HP - 1 PH Electric Motor Mount Assembly

Counter Clockwise Rotation
