Diamond Products CC200 User Manual
Page 5
ITEM NO.
PART NUMBER
QTY.
DESCRIPTION
1
6041032
1
Frame Weldment
2
2501063
3
Bearing, 4 Bolt Flange, 1" ID
3
2900960
12
Cap Screw, Flat Hd., 7/16-14 x 1-1/2"
4
2900045
12
Lock Nut, 7/16-14 Nylon
5
6041055
2
Bearing Cover
6
6041158
1
Gear Box Assembly
7
2900022
25
Flat Washer, 5/16" SAE
8
2900030
5
Cap Screw, Hex Hd., 5/16-18 x 2"
9
2900039
5
Lock Nut, 5/16-18 Nylon
10
6041161
1
Cover Plate Assembly
11
2900031
15
Lock Washer, 5/16" Split
12
2900958
2
Cap Screw, Hex Hd., 5/16-18 x 1/2"
13
2501869
2
Flex Coupling
14
2900693
4
Cap Screw, Hex Hd., 1/2-13 x 3"
15
2900026
4
Lock Nut, 1/2-13 Nylon
16
6041156
1
Axle Weldment
17
6041020
1
Axle Support Shaft
18
2500009
2
Set Collar, 1" ID
19
2503604
2
Wheel, 10 x 3 x 3/4"
20
2400615
2
Set Collar, 3/4"
21
2900698
4
1/2 x 1.2" Quick Pin
22
6011089
1
Key, 1/4" Sq. x 1" Long
23
6041035
1
Guard Retainer
24
2900019
13
Cap Screw, Hex Hd., 5/16-18 x 3/4"
25
6041036
1
Guard, Rear
26
2900947
2
Cap Screw, Soc. Hd., 5/16-18 x 2"
27
2900141
2
Hex Nut, 5/16-18
28
6041051
1
Weight Box
29
2501047
1
Weight
30
6041063
1
Dust Port Bracket
31
6041056
2
Handle Support
32
2900014
8
Flat Washer, 3/8" SAE
33
2900596
4
Cap Screw, Hex Hd., 3/8-16 x 2-1/2"
34
2900018
4
Lock Nut, 3/8-16 Nylon
35
6041023
1
Handle Weldment
36
3200008
2
Close Nipple, 1/2" NPT
37
3200022
1
Fitting, 1/2" F. Pipe to 3/4" F. Garden
38
3200027
1
Water Valve
39
3200155
1
Fitting, 1/2" M. Pipe to 3/4" M. Garden
40
2900257
2
Lock Pin, T Handle, 3/8"
41
2900053
4
Rivet, 3/32" Dia.
42
6040299
1
Water Hose Assembly
43
2503177
1
Hose Reducer, 2.0"-1.5" ID
44
3200095
1
Hose Clamp #32
45
6041065
1
Hose, 2" ID, PVC
46
1800001
2
Warning Label
47
1800506
2
Core Cut Decal
48
1800169
1
Serial Number Plate, US
6041162: CC200 FRAME ASSEMBLY
