TROUBLESHOOTING
PROBLEM POSSIBLE SOLUTIONS
Motor will not start. 1) Pull out stop button on starter box.
2) Press Reset button on starter box.
3) Confirm proper voltage.
Running with no flow. The motor may be running backwards.
Reverse any two of the 3 power wires coming
into the starter box.
System builds high pressure with flow control
valve set to zero. Contamination may have plugged an orifice
in the CF port of the flow valve. Detach the
valve from the front panel and remove the
fitting from the CF port. A .015” orifice should
be visible at the bottom of the port. Push a
fine wire through the orifice and re-install.
Keep this manual and the engine manual readily available at all times for reference.
The engine exhaust from this product
contains chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.
