Page 23
GROUND
3X 4646146
GREEN TO
BLACK
RESET - AUTO
4600165 BROWN
WIRE 8
GROUND FAULT - OFF
AMP RATING
4646128 ORANGE
MOTOR
TO
TO GROUND
4646145 GREEN
COIL TO MOTOR
WIRE 7
TO MOTOR
4646148 ORANGE
TRIP CLASS 10
PHASE UNBAL - OFF
PHASE LOSS - ON
SET TO MOTOR
TO CUSTOMER
SUPPLIED
POWER CORD
4646032 STARTER BOX ASSEMBLY 208 - 460 VOLT
SEE ALSO SCHEMATIC ON MOTOR NAME PLATE.
