4646222 1 Starter Box, 380-440 Volt
6
Lock Washer, #6 Split 2
2 Hex Nut, #6-32
2
2900092
2900090
5
4 2800085
3
Cord, 90 Deg.
3 WIRES TO
Lock Nut, 1"
1 AC Current Transformer
2900091 7
Machine Screw, Rd. Hd., #6-32 x 1/2"
2 2800897
RELAY
OVERLOAD
2 2800193
Cord Connector, 1"Thd., .77-.895"
2
GREEN TO GROUND
ITEM PART NO. QTY. DESCRIPTION
1
ITEM PART NO. QTY. DESCRIPTION
8 2800253 1 Amp Meter w/ Bracket, 0-40 AC
9 4646135 1 Cable, 8 Gage, 4 Wire, 16"
10 4645035 1 Cable Assy., 8 Ga., 4 Wire x 50"
11 1801067 1 Voltage Label, 380V
12 1801638 1 Decal, Start
13 1801639 1 Decal, Stop
4641050 CB20 STARTER BOX ASSEMBLY, 380 VOLT
10
TO MOTOR
SUPPLIED PLUG.
1
TO CUSTOMER
9
A
4
8
7
6
5
11
13
12
SCALE 1 : 3
2
3
2
DETAIL A
3
3 WIRES TO
POWER LUGS,
