4646126/27 WIRING SCHEMATIC, CB 150, 3 PHASE, 230/460/575 VOLT
STOP
1
3
5
2
WIRES IN MOTOR WIRING BOX MUST BE JOINED PER SCHEMATIC ON MOTOR.
POWER CORD
4646135
4646128
14 GA.
BROWN,
4646129
575V, TO MOTOR WIRE 2.
230/460V, TO MOTOR WIRE 8
4646130 BROWN, 14 GA.
BLACK, 8 GA.
230V:
575V, TO MOTOR WIRE 1.
230/460V, TO MOTOR WIRE 7
4646131 ORANGE, 14 GA.
4646132 GREEN
COIL
95
96
GREEN, 6 GA.
4646133
SET OVERLOAD TO 17 AMPS. 460V:
SET OVERLOAD TO 34 AMPS.
SET OVERLOAD TO 14 AMPS. REPLACE COIL WITH 2800277. 575V:
14 GA.
ORANGE,
LUG
GROUND
SETTINGS
5
30
PHASE UNBALANCE - ON
PHASE LOSS - ON
RESET MODE - AUTO
GROUND FAULT - OFF
OVERLOAD
RELAY
