Page 11: Return ports
FLOW CONTROL VALVE
1801441 CB150/240 HYDRAULIC SCHEMATIC
TANK
EXCHANGER
FILTER
PRESSURE PORTS
HOSE 6040061
PUMP
IN
HOSE 4646109
HOSE
4646057 (ELECTRIC)
4646160 (GAS)
HOSE
4646124 (ELECTRIC)
4646108 (ELECTRIC)
6017344 (GAS)
6040057 (GAS)
HOSE
RETURN PORTS
HOSE
HOSE 4646056
90
END TO MANIFOLD
CF
EX
4646078
ALL HOSES ARE IN KITS
4646114 ELECTRIC
4646162 GAS
HEAT
TANK
11
