2702624.
AVAILABLE:
4646163 CB240 GAS COMPONENTS
MUFFLER IS
A CATALYTIC
ITEM PART
NO.
QTY.
DESCRIPTION
1
4646097
1
Frame, Power Supply
2
4646100
1
Instrument Panel
3
4646106
1
Tank / Box Mounting Bracket
4
4641051
1
Honda, GX660, Short Shaft & Elec. Con.
5
2708046
1
Honda Muffler, R Side Exhaust
6
2701670
1
Rectifier Assembly
7
2900009
8
Flat Washer, 1/4" SAE
8
2900052
2
Cap Screw, Hex Hd., 1/4-20 x 1-1/4"
9
2900010
4
Lock Nut, 1/4-20 Nylon
10
4646018
1
Wire Assembly, 12 Gage
11
3201968
1
Adapter, M20x1.5 M. to 3/8" F. Pipe
12
3201468
1
3/8" MPT to 3/8" FJIC, Swivel
13
3205603
1
3/8 MJIC - 3/8 MJIC, 90 Deg.
14
4645037
1
Hose Assy., 3/8 x10-3/4", FJIC-FJIC
15
3201897
1
3/8" JIC Plug
16
2900014
8
Flat Washer, 3/8" SAE
17
2900317
4
Cap Screw, Hex Hd., M10 x 45mm
18
2900304
4
Lock Nut, M10 Nylon
19
6048134
1
Key, 1/4" Sq. x 2-1/4"
20
2702225
1
Coupling Assembly, 3/4 - 1-1/8"
21
2900006
4
Lock Washer, 3/8" Split
22
2900183
4
Capscrew, Soc Hd., 3/8"-16 X 1-3/8"
23
2500584
1
Battery, 12 Volt Group Size U1
24
4646122
1
BatterySupport
25
2901405
2
Cap Screw, Hex Hd., 1/4-20 x 7-1/2"
26
4646015
1
Battery Cable Assy., Red
27
4646016
1
Battery Cable Assy., Black
28
6010869
1
Fuel Tank, 4.4 Gallon
29
2506716
1
Grommet
30
2505503
1
Roll Over Vent, 3/8" Hose Barb
31
2500649
1
Fuel Tank Cap
32
4641107
1
CB240 Vent Line
33
4646136
1
Heat Shield
34
2900022
6
Flat Washer, 5/16" SAE
35
2900019
4
Cap Screw, Hex Hd., 5/16-18 x 3/4"
36
2900039
2
Lock Nut, 5/16-18 Nylon
37
2900031
2
Lock Washer, 5/16" Split
38
3200012
1
Street Elbow, 1/4" NPT
39
3200108
1
Fuel Shut-Off Valve, 1/4"
40
3200418
1
Adapter, 1/4" M. Pipe to 1/4" M. JIC
41
4646210
1
Hose Assy., Fuel, 1/4 x 7.5"
42
2800120
1
Tach/Hour Meter, W/#6 Screws
43
2801367
1
E-Stop Switch
44
4646188
1
Wire Assy., Emergency Off, 46.6"
45
1800943
1
Decal, Core Bore CB240
46
4646162
1
Hose Kit, CB 240
