M-5 Pro Combo Base Assembly #4600190
ITEM
PART NO.
QTY.
DESCRIPTION
1
4600210
1
M-5 Pro Combo Base
2
2900541
4
Tap Bolt, Hex Hd., 1/2-13 x 2-3/4"
3
4600015
1
Base Handle
4
2900247
2
Cap Screw, Soc. Hd., 1/4-20 x 3/4"
5
2400149
1
Spring, 1" Long
6
4600022
1
Vacuum Release Valve
7
4600120
1
Vacuum Pump Platform
8
2900087
4
Cap Screw, Soc. Hd., #10-32 x 5/8"
9
2900016
4
Flat Washer, #10 USS
10
2900086
1
Cap Screw, Hex Hd., 1/2-13 x 1"
11
2900084
6
Lock Washer, 1/2" Split
12
2900058
1
Flat Washer, 1/2" SAE
13
4600046
1
Slot Cap Assembly
14
4600207
1
Mast Support Clamp
15
2400139
4
Clamping Bushing
16
2400140
6
Tension Bushing
17
2900509
2
Cap Screw, Hex Hd., 1/2-13 x 4"
18
2900395
2
Cap Screw, Hex Hd., 1/2-13 x 5"
19
2900037
4
Hex Nut, 1/2-13
20
4600209
1
Stop Bar
21
2900243
2
Cap Screw, Soc. Hd., M8-1.25 x 20mm
22
4600107
2
Angle Brace Tube
23
4600208
1
Mast Sliding Clamp
24
2900129
1
Jam Nut, 1/2-13
25
2900139
2
Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
26
4600132
1
Vacuum Gasket
27
4600211
1
Mount Bar, Control Panel
7
