ITEM PART NO. QTY. DESCRIPTION
1 2503183 1 Vernier Throttle Cable
2 6045115 1 Throttle Bracket
3 2900329 1 Capscrew, Hex Hd., M8 x 20mm
4 2901021 1 Cap Screw, Hex Hd., M10-1.25 x 20mm
5 2900763 1 Lock Washer, M8 Split
6 2900321 1 Lock Washer, M10 Split
7 2901135 1 1/4" 'X' Washer
8 2503945 1 Cable Anchor
9 2900016 3 Flat Washer, #10 USS
10 2900301 1 Lock Nut, M5 Nylon
11 2503918 1 Wire Stop Pivot Pin
12 2900034 1 Cotter Pin, 3/32" x 3/4"
13 2900114 1 Machine Screw, Rd. Hd., #8-32 x 3/8"
13
10
4
6
3 5 2
8
11
12 1
9
7
Throttle Cable Assembly #6045044
(Includes Items #1 - #10)
