Diamond Products CC3500J User Manual
Page 27
ITEM PART
NO.
QTY.
DESCRIPTION
1
6011707
1
Engine Base Weldment CC3500J
2
2900058
2
Flat Washer, 1/2" SAE
3
2900127
2
Flat Washer, 1/2" USS
4
2900026
4
Lock Nut, 1/2-13 Nylon
5
2900499
3
Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
6
2900288
1
Cap Screw, Button Hd., 1/2-13 x 2"
7
2500159
2
Pillow Block Bearing, 3/4"
8
6011710
1
Pivot Plate, Jack Shaft CC3500J
9
2500731
2
Pillow Block Bearing 1-1/2"
10
6010034
1
Key, 3/8" Sq. x 5"
11
6011706
1
Jack Shaft, CC3500J
12
6011708
1
Belt Guard, Jack Shaft CC3500J
13
6048085
1
Idler Arm
14
2900321
3
Lock Washer, M10 Split
15
2900337
1
Cap Screw, Hex Hd., M10-1.5 x 50mm, Full Thd.
16
2900325
2
Hex Nut, M10-1.5
17
2900317
1
Cap Screw, Hex Hd., M10-1.5 x 45mm
18
2900304
1
Lock Nut, M10-1.5 Nylon Insert
19
2900014
4
Flat Washer, 3/8" SAE
20
2500070
1
Spring, Extension, 3/4 Dia x 4
21
2900055
1
Cotter Pin, 3/16" x 1"
22
2900883
2
Cap Screw, Hex Hd., 5/16-18 x 5/8"
23
2900006
6
Lock Washer, 3/8" Split
24
2900473
4
Flat Washer, 3/8" USS
25
2900029
2
Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
26
2900062
4
Grease Fitting, 1/8" NPT
27
2500074
1
Idler Pulley 3"
28
2900086
4
Cap Screw, Hex Hd., 1/2-13 x 1"
29
2900005
4
Cap Screw, Hex Hd., 3/8-16 x 1"
30
2900084
4
Lock Washer, 1/2" Split
31
2900104
1
Tap Bolt, Hex Hd., 5/8-11 x 6"
32
2900112
3
Hex Nut, 5/8-11
33
2900492
2
Tap Bolt, Hex Hd., 5/8-11 x 4"
34
2900446
2
Swivel Pad Nut, 5/8-11
35
3201276
8
1/4" Compression Tube Fitting
36
3201462
4
Nipple, 1/8" NPT X 1-1/2"
37
3200154
2
Pipe Elbow, 1/8" NPT Female
38
6011715
2
Grease Tube, 1/4" x 7"
39
6011748
2
Nylon Grease Tube, 1/4" x 14"
40
2900018
2
Locknut, 3/8-16, Nylon
41
3200388
2
1/8" Pipe Coupling
6011712 Parts List
27
