4.0 Maintenance • Parts Listing
Parts Listing
Chart 4.2 • Direct Spark NFS-2/PFS-2 Control Components
Part No. Description
Voltage
VR8205A-2123 Combination gas valve, natural gas 25V
VR4205M-1308 Combination gas valve, natural gas 120V
DR-V24LP Combination gas valve, propane gas 25V
VR4205M-1357 Combination gas valve, propane gas 120V
32-508 Main burner electrode 25V, 120V
Mark 10DX-24 25V circuit board 25V
DRWH-24 Wiring harness for Mark 10DX-24 circuit board 25V
Mark 10DX-117 120V circuit board 120V
DRWH-120 Wiring harness for Mark 10DX-117 circuit board 120V
HVW-18 High voltage ignition wire 25V, 120V
LVW-18 Low voltage ignition wire 25V, 120V
Chart 4.3 • Millivolt NMV-2/PMV-2 Control Components
Part No. Description
VS820A-1070 Combination gas valve, natural gas
VS820A-1740 Combination gas valve, propane gas
Q313A-1014 Pilot flame detector powerpile
F10-1 Pilot burner
69-1818 Pilot orifice, natural gas
69-0764 Pilot orifice, propane gas
RV 12-6” Pilot regulator, natural gas
RV 12-11” Pilot regulator, propane gas
RK-130 Millivolt Thermostat
MV-WIRE 35’ Thermostat Wire
Chart 4.4 • Miscellaneous Core Components
Part No. Description Part No. Description
DR-MAN# Manifold DR-EMB Electrode mounting bracket (NFS-2/PFS-2)
DR-UF#* Upper frame (*specify 1-5) DR-RSB Red Rubber Spark Boot (NFS-2/PFS-2)
DR-HS#* Heat shield (*specify 1-5) DR-LVG Low volt black wire grommet (NFS-2/PFS-2)
DR-FLSH#* Flash shield (*specify 1-5) DR-HVG High volt black wire heyco grommet (NFS-2/PFS-2)
DR-RFE# Reflector End (*specify 1-5) JB-0514 JB-0514 metal junction box (NFS-2/PFS-2)
DR-#REF* Full Reflector Assembly (*specify 1-5) DR-8SMS #8 x 1/2” common sheet metal screw
DR-SF Side frame DR-20MB 1/4 - 20 x 1/2” machine screw (DR Bolt)
DR-SFI Side frame insert DR-20HN 1/4 - 20 hex nut (mates to DR bolt)
DR-ERS Embossed reflector sides DR-20STB 1/4 - 20 x 1/2” self-tap DR bolt
DR-RH Rayhead with center support DR-10EMS 1/4 - 10 short electrode mounting screw
DR-RHP Rayhead no center support
(DR 30-45 LP models only)
DR-8STS #8 x 1/2” sheet metal self-tap screw
DR-CO Cross-over bracket DR-DOOR Pilot access door with zip screw (NMV-2/PMV-2)
DR-LROD Long rayhead rod F10-PS Pilot shield for F10-1 pilot burner (NMV-2/PMV-2)
DR-SROD Short rayhead rod PL-1 Pilot line for DR 30 (NMV-2/PMV-2)
DR-MU Union fitting, 3-piece PL-2 Pilot line for DR 45-DR 160 (NMV-2/PMV-2)
ORF-# Brass gas orifice (specify model #) DR-PJBT Plastic junction box (Top)
DR-FC 3/8” flex conduit (NFS-2/PFS-2) DR-PJBB Plastic Junction Box (Bottom)
DR-FL31 3/8” conduit attachment fitting (NFS-2/PFS-2)
*Reference proper part number when ordering these parts: 1=DR30; 2=DR45-60; 3=DR75-100; 4=DR 130, 5=DR 160
Visit our online parts reference library at www.reverberray.com for further part related technical data.
IMPORTANT: Contact factory for conversion assistance. Note: Gas type conversions require gas
valve and gas orifice among other changes Conversion may also require burner and crossover changes.
