AVOID EQUIPMENT FAILURE
THIS 10 FT. TUBE IS THE
COMBUSTION CHAMBER.
THIS TUBE MUST BE THE FIRST TUBE
FOLLOWING THE BURNER CONTROL BOX.
! INSTALLER
The combustion chamber utilizes either 409
stainless, titanium alloy or aluminized steel -
depending on the model number of your heater.
Rotate the tube’s welded seam to bottom.
Consult the manual(s) for further details.
F/N: LL01 - Clearance Safety Tag
(Affix adjacent to heater’s thermostat)
®
DETROIT RADIANT PRODUCTS COMPANY 21400 HOOVER ROAD - WARREN, MI
RE-VERBER-RAY INFRA-RED RADIANT TUBE HEATER
FOR INDOOR (Non-Residential) INSTALLATION ONLY.
Class IIIA Permanent Label
(586) 756-0950 - www.drp-co.com
Volts AC:
AMPS - Starting:
AMPS - Running:
Combustion Chamber:
120VAC - 60Hz
1.7
1.1
4” Black Coated Aluminized
DESIGN COMPLIES WITH: ANSI Z83.20b-2004-GAS FIRED LOW INTENSITY INFRA-RED HTR.
Manifold Pressure:
Maximum Inlet Pressure:
Minimum Inlet Pressure:
3.5 in.
14 in.
5.0 in.
Inches W.C.P.
Inches W.C.P.
Inches W.C.P.
Serial No.: 1208XXXXXXXXXX 0001
MODEL NO. DET-40-125N(-3)
Heater Type
Minimum Mounting Angle:
Maximum Mounting Angle:
C1
0
45
DEGREES
DEGREES
INPUT BTU/H 125,000 / 95,000 FOR USE WITH Natural Gas
SERVICE ACCESS PANEL IGNITER & FLAME SENSE COMPARTMENT
1. Disconnect gas & electricity. 2. Remove cover by lifting top cover upward and outward.
CAUTION: HOT SURFACE. KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.
S3
Clearance to Combustibles is defined as the minimum distance that must exist between the tube surface,
or reflector, and any combustible items (see Figure 1.1). It also pertains to the distance that must be
maintained from moving objects around the tube heater. When installing the tube heater system, clearances
to combustibles for the model tube heater and configuration must be maintained. Refer to Chart 1.1 to
determine the required distances for your model.
Clearance to Combustibles
F/N: LLTB004 (orange)
WARNING
!
Placement of explosive objects, flammable objects, liquids and vapors close to the heater
may result in explosion, fire, property damage, serious injury or death. Do not store, or
use, explosive objects, liquids and vapor in the vicinity the heater.
16” Burner
Tube
Primary Combustion
Chamber
Secondary Combustion
Chamber (if applicable)
ALUMINIZED TUBE
(This is the Second Chamber)
This tube is constructed of aluminized coated steel and must be
placed directly after the titanium coated “Combustion Chamber”
(orange labeled tube).
150,000-200,000 BTU/h
models only
F/N: LLTB026 F/N: LLTB024R
F/N: LLTB025
SERVICE ACCESS PANEL
IGNITER & FLAME SENSE COMPARTMENT
1. Turn off gas & electricity.
2. Remove cover by lifting top
cover upward and outward.
CAUTION: HOT SURFACE.
KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.
SERVICE ACCESS PANEL
SERVICE ACCESS PANEL
Fan
Compartment
Controls
Compartment
Burner Control Box Component Label
(affixed to center valve compartment lid)
Rating
Plate
4
DES3 Series
®
DETROIT RADIANT PRODUCTS COMPANY
21400 HOOVER ROAD - WARREN, MI
RE-VERBER-RAY INFRA-RED RADIANT TUBE HEATER
FOR OUTDOOR USE AND INDOOR (Non-Residential) INSTALLATION ONLY.
Class IIIA Permanent Label
(586) 756-0950 - www.drp-co.com
Volts AC:
AMPS - Starting:
AMPS - Running:
Combustion Chamber:
120V - 60Hz
1.7
1.1
4” Black Coated Aluminized
DESIGN COMPLIES WITH:
ANSI Z83.20b-2004-GAS FIRED LOW INTENSITY INFRA-RED HTR.
Manifold Pressure:
Maximum Inlet Pressure:
Minimum Inlet Pressure:
3.5 in.
14 in.
5.0 in.
W.C.P.
W.C.P.
W.C.P.
Serial No.: 0807XXXXXXXXXX 0001
MODEL NO.
DES-40-125N(-3)
Heater Type
Minimum Mounting Angle:
Maximum Mounting Angle:
C1
0
45
DEGREES
DEGREES
INPUT BTU/H
125,000
FOR USE WITH
Natural Gas
1.0 Safety • Safety Labels and Locations • Clearance to Combustibles
DET-40-125N(-3)
Data on this label is for the model shown on this label. If your heater has been converted,
this information is not accurate. Please contact the factory for assistance.
BURNER COMPONENTS:
For parts replacement information, contact factory at 586-756-0950 or visit www.drp-co.com/parts.
Serial No.: 0804XXXXXXXXXX 0001
Gas Valve:
Circuit Board:
Wire Harness:
N.O. Switch:
N.O. VL Orifice:
N.C. Switch:
N.C. VL Orifice:
Diff Switch:
Diff VL Orifice:
Igniter:
Burner:
16” Tube:
Ind. Lights: Diag. Light:
Term. Block:
Transformer:
Fan:
Alt. Fan:
Alt. Fan Usage:
Relay:
Filter:
24 Volt In:
120 Volt In:
Gas In:
Extra VL Orifice:
Production Code:
Version: Stock:
Add-On:
Internal Use Only: HEATER
TYPE: Electric:
Tag: Special 1:
Special 2: Gas:
Air: C1
C1 C2 C3
None
N/A
DET3-125
7.08
36G54-224-N
MARK10DX-117
3 PCS Harness
None
None
None
None
IS22010051F5166
Grey (+ / -)
Norton
Mid
4” Gen.
Yellow - 24V
(Specify TP-#’s)
840
851
852
N/A
N/A
264E
50
201B
380
828
On Circuit Board
None
40 VA
Fasco Lg.
50Hz - 120V
When Specified
None
None
3 T-plug
6’ Blk. Cord
7/8” FC
None
N/A
826
55A
55B
N/A
N/A
832
333
83
19
1 5/16”
TP-204#
TP-44# 19
1 7/16”
LLWT038
None 19
1 5/16”
17
1 7/16”
Orifice Type:
DES-40-125N(-3)
DES3-125
SA
MP
LE
SA
MP
LE
