Maintenance and Care
5.4 Battery Systems
1 LDS display
2 Charger indicator
3 Charger
4 Mains cable charger
5 Battery connector
6 Batteries
7 Recovery tank
8 Support
9 Wiring diagram
Handling and changing the
batteries may be performed
only by maintenance staff.
Fig.7
4 3
1 2
6 5
8
7
9
