Minuteman E Ride 21 - Manual (Page 18)

3-8
Wash-and-dry machine body dimensions, with squeegee and brush (length x
height x width)
1200 x 1130 x 600 mm 1200 x 1130 x 600 mm
Wash-and-dry machine net weight (without batteries, with empty tanks,
without driver)
148 Kg 145 Kg
Wash-and-dry machine gross weight (with batteries, with one full tank,
without driver)
~ 250 Kg ~ 247 Kg
Drive motor 400 W 400 W
Disc brush motor 400 W -
Motor cylindrical brushes - 600 W
Motor suction 400 W, 3 stages 400 W, 3 stages
Manufacturing Regulations CE CE
Protection class IPX 4 IPX 4
Level of acoustic pressure A at working position 72.4 dB (A) 72.4 dB (A)
Level of acoustic power A 87.6 dB (A) 87.6 dB (A)
Description
E Ride 21
(with one disc brush)
E Ride 21
(with two cylindrical
brushes)
