1.4 Specifications
Processor Sys-
tem
CPU (45 nm
µFC-PGA 478) Intel ® Core™2 Duo Intel Celeron M
Max. Speed T9400 2.53 GHz 575 2.0 GHz
Front Side Bus 667/800/1066 MHz 667 MHz
L2 Cache 6 MB 1 MB
Chipset GM45 + ICH9M
BIOS Award 16 Mbit, SPI
Expansion Slot
PCI -
Mini-PCI -
PCIe x 16 4 GB/s per direction, 1 slot
Memory
Technology DDR3 800/1066 MHz SDRAM
Max. Capacity 4 GB
Socket 2 x 204-pin SODIMM
Graphics
Controller Intel GM45 GMCH integrated Graphics Media Accelerator X4500
VRAM Shared system memory up to 384 MB video memory
LVDS Single channel 18/24-bit/Dual channel 36/48-bit LVDS
DVI-D Yes (if DVI is used, PCIe x16 is automatically disable)
Dual Display VGA + DVI; VGA + LVDS; DVI + LVDS
*Dual Display
Mode Extended Mode, Clone Mode, Twin Mode
Ethernet
Interface 10/100/1000Base-T
Controller GbE LAN1: Realtek RTL8111C; GbE LAN2: Realtek RTL8111C
Connector RJ-45 x 2
SATA
Max Data Trans-
fer Rate 300 MB/s
Channel 2
SSD Compact Flash Compact Flash Supports compact flash type I/II
Rear I/O
VGA 1
DVI 1
Ethernet 2
USB 4 (USB 2.0 compliant)
Serial 2 (1 of RS-232, 1 of RS-232/422/485)
PS/2 2 (1 x keyboard and 1 x mouse)
Internal
Connector
LVDS 1
USB 4 (USB 2.0 compliant)
Serial 4 (RS-232)
IDE -
SATA 2
Audio 3 (Mic-in, Line-in, Line-out)
Compact Flash 1
Parallel -
IrDA -
FDD -
DIO 16-bit General Purpose I/O for digital signal input/output
Watchdog
Timer Output Interrupt, system reset
Interval Programmable 1 ~ 255 sec/ min
