- 28 -
Inverter Electrical Specification:
For Fujitsu FLC488SC8V-10 (AL1912 m)
Condition Min. Typ. Max. Unit
Input Voltage --- --- 15 --- V
Input Current --- --- 1.5 --- A
ON 3.3 V Backlight ON/OFF Control
OFF 0 V
Brightness Adjust
Min. Luminance / Max.
Luminance
--- 30% --- ---
Output Voltage Vin=15V, Iout=6.5mA --- 750 --- Vrms
Brightness lamp current in 6.5mA 250 300 Cd/m²
Output Current(Each connector) Vbri=0.4V~3.3V 4 7 8 mA
Frequency --- 40 50 60 KHz
Lamp start voltage @0℃ 1600 --- --- Vrms
Striking Time --- 1 --- S
Lamp Current Balance --- --- ±0.3 --- mA
Efficiency Vin=15V --- 80 --- %
Operating Life Time --- 50000 --- --- Hr
*.The open lamp voltage is testes at output connector terminal
SAFETY
Leakage Current: 0.25mA @ 100Vac
Insulation Resistance: more than 3M ohms while withstanding a voltage of 500Vac
Hi-Pot: 3Kvac with using 3mA cut off current
