Monitor block diagram – Acer AL1912 User Manual
Page 15
- 15 -
MONITOR BLOCK DIAGRAM
The LCD monitor will contain an main board, an inverter/ power board, key board and internal adapter which house the
flat panel control logic, brightness control logic and DDC.
The inverter board will drive the backlight of panel and the DC-DC conversion.
The Adapter will provide thr 12V DC-power to inverter/ power board.
Power board
(include: AC/DC,inverter)
