Max Machinery, Inc. 210 Series User Manual © Copyright 2013

Rev. 002Q4

8

Supply Voltage

5-26 Vdc

Supply Current

25-30 mA typical

Output (5.0 Volt Supply)

No Load

0.00 / 4.80 Volts

(TTL and CMOS compatible)

2.5K Load to Common

0.00 / 4.60 Volts

2.5K Load to +5 Volts

0.25 / 4.80 Volts

Short Circuit Current

45 mA

Output Impedance

100

Ω

Rise/Fall Time

0.2

μSec

1

Output Update Rate

1 ms

Min/Max Frequency

0-60 kHz

Resolution

1 - 1000 pulses/rev, Single Phase

1 - 500 pulses/rev/phase, Quadrature

Ambient Temperature Range

Transmitter (Storage)–40ºC to 85ºC (–40ºF to 185ºF)

2

Transmitter (Operation) –40ºC to 80ºC (–40ºF to 175ºF)

Maximum Temperature,

Process Fluid (20ºC Ambient, 5V supply)

For explosion proof models see:

www.maxmachinery.com/content/explosion-proof-installation-instructions

29X-X0X-XXX Standard Model 90ºC (195°F)

29X-X5X-XXX High Temp Model — 2 part model 225ºC (435°F)

Anti-dither Range

Software selectable from 1-100% of 1 revolution.

50% of a meter revolution - unidirectional - 2% bidirectional

are typical default settings


Signal Filtering

Software selectable from 1ms to 250ms time constant

1

Full step change is subject to signal damping

2

Temperature of metered fluid will affect transmitter temperature, see graph on previous page

Transmitter Specifications

Frequency (Pulse)
