Max Machinery, Inc. 210 Series User Manual © Copyright 2013 Rev. 002Q4 16
P002 Piston Flow Meter
Pressure Drop (psi)
TYPICAL PRESSURE DROP (Delta P versus Flow rate for various viscosities)
0
30
35
5
10
15
20
25
1 2 3 5 10 20 30 50 100 200 300 500 1000 2000 3000
—2 bar
—1.5 bar
—0.5 bar
Expected Failure Area
30c
P
Intermittent Duty Area
Continuous Duty Area
300
0 cP
10
00 c
P
30
0 cP
100
cP
3 cP
—1 bar
BOTTOM VIEW
MODEL P002 WITH INDUSTRIAL
HOUSING TRANSMITTER
MODEL P002 WITH EX-PROOF
HOUSING TRANSMITTER
EX-PROOF HOUSING
TOP VIEW
not to scale
2.26”
(57mm)
2.26”
(57mm)
0.65”
(17mm)
1.96”
(50mm)
5.51
(140mm)
3.62
(92mm)
2.26”
(57mm)
5.98
(152mm)
3.62
(92mm)
2.26”
(57mm)
Inlet port
locations
mounting holes
10-32NF
(4) Places
