Max Machinery, Inc. 210 Series User Manual © Copyright 2013

Rev. 002Q4

6

Meter Specifications

Model

213

P002

214

215

216

1

Maximum flow rate

Gal/min:

0.48

0.53

2.64

9.25

26.4

Liters/min:

1.8

2.0

10

35

100

Maximum pressure (psi)

2xx-3xx, 2xx-4xx:

1,000 psi (70 bar)

2xx-6xx:

3,000 psi (210 bar)

P002, 214-5xx

7,250 psi (500 bar)

Pressure drop (PSIG)

Operating maximum:

15

15

28

30

30

Absolute maximum:

20

20

30

42

42

100% Flow (3cps):

3.25

3.25

3.5

5

9

2

Maximum temperature

--------------------- 1 part: 195°F (90°C) --------------------

2

Maximum temperature

-------------------- 2 part: 435°F (225°C) --------------------

3

Recommended filtration

10 micron

10 micron

10 micron

10 micron

10 micron

Displacement (cc/rev)

0.887

1.0

10.5

47.6

169.5

Weight (lbs)

1000 & 3000 psi

1.25 (0.57Kg)

---

6.25 (2.8Kg)

22.75 (10.3Kg)

55.25 (25.1Kg)

7250 psi

---

4.2 (1.9kg)

14.4 (6.5)

---

---

Typical k-factor (pulses/cc)

290 Frequency series

Transmitter

1000

1000

90

20

5

Port size (NPT):

0.125”

---

0.375”

0.500”

0.750”

SAE

#4 #4 #6 #12 #18

1

For viscosities of 30 cps or more, derate per pressure drop curves for higher viscosities.

2

Dependent on meter seal material, transmitter model, orientation and ambient temperature. See transmitter manual;

consult factory.

3

Some materials may have different filter requirements, consult factory.
