Max Machinery 216 Piston Flow Meter User Manual
Page 2
Max Machinery, Inc. 210 Series User Manual © Copyright 2013
Rev. 002Q4
2
Table of Contents
Max Machinery, Inc. (MMI) reserves the right to make changes to the product in this Instruction Manual to improve performance, reliability, or
manufacturability. Consequently, contact MMI for the latest available specifications and performance data. Although every effort has been made to
ensure accuracy of the information contained in this Instruction Manual, MMI assumes no responsibility for inadvertent errors.
Meter General Description .................................................................. page 4
Transmitter General Description ....................................................... page 5
Transmitter Specifications Analog ................................................... page 7
Transmitter Specifications Frequency (Pulse) ............................... page 8
Installation .............................................................................................page 10
Operation ................................................................................................ page 11
Electrical Installation - Wiring ...................................................... page 12-13
Diagrams & Pressure Drop:
213 Piston Flow Meter ..........................................................page 15
P002 Piston Flow Meter .....................................................page 16
214 Piston Flow Meter ......................................................... page 17
215 Piston Flow Meter .........................................................page 18
216 Piston Flow Meter .........................................................page 19
Contact for Repairs & Calibration Services ..................................page 20
Custom Instructions for Hazardous Locations/Explosion Proof Housing:
DO NOT ATTEMPT TO INSTALL OR START FLOW METER WITHOUT READING THIS ENTIRE MANUAL
