Supermag, Ii, iii, and iv sprintmag, And sprintmag – Mallory Ignition Mallory MAGNETO IGNITION SYSTEMS SPRINTMAG, SPRINTMAG II,III User Manual
Page 3: Ii magneto
3
MALLORY IGNITION
www.malloryracing.com
FIGURE 2
SUPERMAG
®
II, III, AND IV
SPRINTMAG
®
AND
SPRINTMAG
®
II MAGNETO
FIBER-OPTIC PICK-UP (IF USED)
TO ENGINE
GROUND
TO ENGINE
GROUND
RED
ORANGE
YELLOW
HARNESS
PN 28862
SET STATIC TIMING
(BUZZ) FROM HERE
HARNESS
PN 28998
KILL SWITCH PN. 26074
NOTE: ON A DUAL MAG ENGINE, A KILL SWITCH IS REQUIRED FOR
EACH MAG. DO NOT USE ONE KILL SWITCH TO CONTROL BOTH MAGS.
